2
PANEL DESCRIPTION
Assignable Software key functions (Continued)
LCD Mode
Push to select the LCD Mode.
• Day : The LCD is set to the Day mode.
The Day mode is for the daytime operation,
and the display backlight color is set to
white.
• Night : The LCD is set to the Night mode.
The Night mode is for the nighttime
operation, and the display backlight color is
set to black.
Category: Control Head Setting
( For only the revision 2.00 or later Moblie type
transceivers)
Intercom
Push to turn the Intercom function ON or OFF.
This function enables the user to communicate
between the optional control heads.
D For the AB Switch
(For the Portable type transceiver)
Functions can be assigned to the AB Switch.
NOTE: The function that is assigned to the AB
Switch, cannot be assigned to any key.
Transceiver's top view
Assignable
function
Conventional Trunking 2-Tone MDC
Null (p. 2-21)
Zone (p. 2-21)
Prio-A (p. 2-21)
Prio-B (p. 2-21)
Lock (p. 2-21)
Lone Worker
(p. 2-21)
High/Low
(p. 2-21)
Talk Around
(p. 2-21)
Surveillance
(p. 2-21)
Scrambler/
Encryption
(p. 2-21)
Compander
(p. 2-21)
Site Lock
(p. 2-21)
✓: Applicable
N/A: Not Applicable
2-20
Digital (P25) Analog
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
✓ ✓ ✓
N/A N/A
✓
N/A N/A
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
✓
N/A
