Icom IC-F7010 Series Operating Manual page 35

3
BASIC OPERATION
Selecting a channel (Continued)
D Selecting an NAC channel
<Key operation>
1. While in the Digital mode, push [Tone/NAC CH
Select] to display the "NAC CH Select" screen.
2. Push [Up] or [Down] to select an NAC channel,
then push [OK].
• Sets the selected channel.
<Menu operation>
(Menu > Channel/Scan > NAC CH Select)
1. While in the Digital mode, push [Menu] to display
the "Menu" screen.
2. Push [Left] or [Right] to select "Channel/Scan,"
then push [OK].
3. Push [Up] or [Down] to select "NAC CH Select,"
then push [OK].
• Displays the "NAC CH Select" screen.
4. Push [Up] or [Down] to select an NAC channel,
then push [OK].
• Sets the selected channel.
5. Hold down [Back] for 1 second to return to the
standby screen.
• The selected NAC channel number is displayed.
3-6
