2
PANEL DESCRIPTION
Assignable Software key functions
D For keys and keypads (Continued)
Category: Channel/Scan (Voting) (Continued)
Compander
In the Analog mode
Push to turn the Compander function ON or OFF.
L The Compander function reduces noise components on
the transmit audio to provide clear communication.
Category: Signaling/Call
Call
In the Analog mode
Push to make a call to the preset destination in the
channel.
Re-dial
Push to send the last transmitted DTMF code number.
L Redial will be cleared when the transceiver is turned OFF
once.
Call Menu
1. Push to display the "Call Menu" screen.
2. Push [Up] or [Down] to select a call function.
L See 'Transmitting a call' on sections 7 and 8 for
details.
3. After selecting, push [OK] to set, and display the
call function screen.
4. Push [Up] or [Down] to select an ID name (or ID
code).
5. After selecting, push [PTT] to make a call to the
selected station or group.
DTMF Autodial
z Push to display the "DTMF Autodial" screen. Then,
push [Up] or [Down] to select a DTMF code. After
selecting, push [PTT] to transmit the selected DTMF
code.
z While in the Standby mode, hold down for 1 second
to transmit the currently selected DTMF code.
Emergency
1. Hold down during the Emer SW ON Timer period
to enter the Emergency mode.
2. After the Reminder Timer period has passed, an
Emergency call is automatically transmitted once,
or repeatedly.
NOTE:
• Set the related settings using the programming
software.
• This key function is assignable to only [Emer] or
[Ext. Emer].
L Hold down during the Emer SW OFF Timer period to
cancel the Emergency function, before transmitting an
Emergency call.
Power OFF Emergency
(For the Mobile type transceivers)
While holding down this key, turn OFF the transceiver
to activate the Power OFF Emergency function.
NOTE: This key function is assignable to only [Emer]
or [Ext. Emer].
LInformation
• This function makes the transceiver transmit
Emergency calls, even though it appears to be
powered OFF.
• When the function is activated, any key operation,
hanger action and Lone Worker function becomes
invalid, as well as the Status indicator and speaker
become the same as being powered OFF.
On the other hand, the transceiver can transmit
Emergency calls according to the Emergency
settings, and the Ambience Listening function is also
activated, if it is set.
• To cancel the function and restore the transceiver,
turn ON the transceiver.
Individual
In the Digital mode
Push to display the "Individual ID" screen. Then, push
[Up] or [Down] to select an Individual ID name (or ID
code).
After selecting, push [OK] to set.
Group
In the Digital mode
Push to display the "Group ID" screen. Then, push
[Up] or [Down] to select an Group ID name (or ID
code).
After selecting, push [OK] to set.
Call Alert
Hold down for 1 second to transmit a Call Alert.
Status
Push to display the "Status List" screen. Then, push
[Up] or [Down] to select a Status message.
L See pages 7-6, 8-14 for details.
Message (Short Message)
While in the Standby mode, push to display the
"Message List" screen. Then, push [Up] or [Down] to
select a message.
L See pages 7-3, 8-4 for details.
2-16
