Dakota Ultrasonics
1) Press the
multiple times to tab right and the
DISP menu is highlighted and displaying the submenu items.
2) Press the
menu items until BACKLIGHT is highlighted.
3) Press the
options.
4) Finally, press the
taking readings.
13.4 Graphics Options (look & feel)
The MiniMax has a few graphical 'look and feel' options to accommodate user
preference. These features only serve as cosmetic items and do not change the
functionality of the MiniMax in any way.
RECT Wave:
The rectified wave feature is only functional when using RECT wave view, and
provides the user the following display options:
Outline – Draws the unfilled outline of the waveform.
key once to activate the menu items tab. Press the
and
arrow keys multiple times to scroll through the sub
and
arrow keys multiple times to scroll the BACKLIGHT
key to return to the measurement screen and begin
key multiple times to tab left until the
150
key
