Get Started
3.5

GX Works2 (Q-CPU) Telegram 102 example

This chapter describes running the inverter through the A8NDPV1 Profibus option card using
GX Works 2 with a QCPU and QJ71PB92V Profibus Master. First perform the setup using
telegram 1.
Enter the Profibus Configurator and double click on the inverter to bring up the Slave Param-
eters Wizard. Click Next to proceed.
A8NDPV1 PROFIBUS Option Board
GX Works2 (Q-CPU) Telegram 102 example
29
