Data Exchange

7. Data Exchange
7.1

General Information

Inverter parameters can be accessed acyclically by means of the PROFIdrive Parameter Protocol.
The master issues a parameter request to the option board. The option board processes the re-
quest. Meanwhile the master repeatedly tries to read the parameter response, but an error mes-
sage will be returned until the request is fully processed by the module, after which the master
can read the response.
Translation of signal numbers
Signal numbers used in the inverter do not directly translate to signal numbers (PNUs) used on
PROFIBUS. An offset is added to avoid ambiguous numbering on PROFIBUS, where parameters
and monitor data have different PNU numbers.
The array below presents a summary of the signal number translation. For a complete presenta-
tion of how to translate the signal numbers for the option board drive profile parameters, see
"Translation of Signal Numbers" on page 147.
Signal Type
Parameter
Monitor Data 000h...3FFh
Option Board
Drive Profile
Parameters
1
Some of these parameters can be mapped for cyclic data exchange, see "Translation of Signal Num-
bers" on page 147.
2
These parameters can either be accessed (as acyclic data) as an array, with offset 13288d, or can
each entry in the array be mapped as a separate parameter with offset 15336d (as acyclic and/or
cyclic data).
A8NDPV1 PROFIBUS Option Board
Signal No, Main Unit
Hexadecimal Decimal
0h...54Fh 0...1359d
0d...1023d
400h...411h 1024d...1041d
412h, 1042d,
2 1045d...1052d
415h...41Ch
413h...414h 1043d...1044d
41Dh...431h 1053d...1073d
PNU No,
PROFIdrive
Offset
(Signal No. +
Offset)
5096d 5096d...6455d
9192d 9192d...10215d
13288d 14312d...14329d
14330d,
2
13288d
14333d...14340d
2 16378d,
15336d
16381d...16388d
13288d 14331d...14332d
13288d 14341d...14361d
General Information
Acyclic Cyclic
Data Data
Exchange Exchange
Yes No
Yes Yes
Yes 1
Yes/no
Yes No
Yes Yes
Yes No
Yes 1
Yes/no
