Inverter parameters (Acyclic Data Exchange)

7.2
Inverter parameters (Acyclic Data Exchange)
Inverter parameters are available only via acyclic communication. They cannot be used in cyclic
data exchange, for example it is not possible to map them as parameters for telegram 102. The
offset used for inverter parameters is 5096, i.e. inverter parameter no. 1 (maximum frequency)
shall be addressed as PNU 5097. An example of reading writing inverter parameters is shown in
"Reading a parameter (Sequence 1)" on page 34.
All of the inverter parameters are unsigned 16bit integers, with the exception of the following:
Parameter
7
8
16
44
110
111
264
265
791
792
All other
7.3

Monitor Data (Acyclic and Cyclic Data Exchange)

This chapter contains a table of monitor data available via both cyclic and acyclic data exchange.
The values are available as 16 and 32 bit integers. To calculate the actual monitor data value, the
returned integer should be multiplied by the unit specified for that parameter. For example if
PNU 9193 (output frequency) is requested and a value of 500 is returned, this means that the out-
put frequency is equal to 5 Hz (500 × 0.01 Hz).
PNU No
9193
9194
9195
9196
9197
9198
9199
9200
9201
9202
9203
9204
9205
9206
9207
9208
126
PNU
Description
5103
Acceleration time
5104
Deceleration time
5112
Jog acceleration/deceleration time
5140
Second acceleration/deceleration time
5206
Third acceleration/deceleration time
5207
Third deceleration time
5360
Power-failure deceleration time 1
5361
Power-failure deceleration time 2
5887
Acceleration time in low-speed range
5888
Deceleration time in low-speed range
-
All inverter parameters NOT listed in this table
Internal No Description
1
Output frequency
2
Output current
3
Output voltage
4
reserved
5
Frequency setting value
6
Motor speed
7
Motor torque
8
Converter output voltage
9
Regenerative brake duty
10
Electric thermal relay function
11
Output current peak value
12
Converter output voltage peak value
13
Input power
14
Output power
15
Input terminal status
16
Output terminal status
Unit
16 bit
0.01Hz
0.01A/0.1A unsigned
0.1V
-
0.01Hz
1 rpm
0.1%
0.1V
0.1%
0.1%
0.01A/0.1A unsigned
0.1V
0.01/
0.1kW
0.01/
0.1kW
*1
-
-
*2
Data Exchange
Data type
Unsigned 32 bit integer
Unsigned 16bit integer
Access
Type
type
unsigned
R
R
unsigned
R
-
-
unsigned
R
unsigned
R
unsigned
R
unsigned
R
unsigned
R
unsigned
R
R
unsigned
R
unsigned
R
unsigned
R
-
R
-
R
Doc.Id. HMSI-216-127
Doc.Rev. 1.01
