Parameter Settings

3.16.2

Download Configuration

The configuration of the PROFIBUS network can be built offline. To download the configuration
to the physical network, follow the steps below:
Power up network.
Set node address for each individual module using the parameter unit.
Download the configuration to the master. How this is done depends on which configuration
tool is used.
If errors occur during the connection phase, scan the network and use the live list to find the
slaves. Make sure that the node addresses are correct, otherwise they can be changed to
match the configuration.
3.16.3

Run

Set the PLC in RUN mode.
3.17 Parameter Settings
Parameters can be set at runtime using the hand-held parameter unit or the setup software MEL-
SOFT FR-Configurator
been restarted.
For more information, please consult the manual for the FR-A800 or FR-F800 series frequency in-
verter.
1
Node addresses can also be set from a master or a configuration tool. See the manual or online help for the configuration
tool you are using. The PNU ident number of the A8NDPV1 PROFIBUS Option Board is 18E0h.
2
See the product pages at https://eu3a.mitsubishielectric.com.
116
2
. The values of some of parameters will not be valid until the module has
Get Started
1
Doc.Id. HMSI-216-127
Doc.Rev. 1.01
