Inverter Settings

4. Inverter Settings
4.1

Inverter Parameters

The inverter parameters are critical for overall operation of the end-to-end communication sys-
tem. Some of these parameters must be set to specific values, and some may have multiple al-
lowable settings depending on the desired operation of the overall application. It is important to
understand the manner in which the parameters will impact successful communications with,
and control of the inverter.
The inverter parameters can be changed via the handheld parameter unit or using the setup soft-
ware MELSOFT FR-Configurator
for the FR-A800 or FR-F800 series.
4.2

Option Board Parameters

The option board parameters are stored in the inverter. At startup they are transferred from the
inverter to the option board and can be changed using the parameter unit and the setup soft-
ware MELSOFT FR-Configurator
The option board parameters are stored in the main unit. At startup they are transferred from the
inverter to the option board.
No (dec)
1300
1301
1302
1303
1304
1305
1306
1307
1308 - 1343 51Ch-53Fh
1
During startup the option board will verify value of this parameter. If it differs from the network type
of the option board, the option board will change the parameter value to the actual network type
and clear all other parameters.
2
During startup the option board will verify the value of this parameter. If it differs from the serial
number of the option board, the option will board will change the parameter value to the actual
serial number and also set the option board host name to [main-unit-name]-[serial number]
The option board and the inverter start up with default standard settings. Any changes of the pa-
rameter values during runtime, will not be available until the inverter has been restarted.
The application can more often than not be run on standard settings.
1
See http://eu3a.mitsubishielectric.com/fa/en/products/drv/inv/fr_configurator/
A8NDPV1 PROFIBUS Option Board
1
. The handheld parameter unit is described in the user manual
1
.
No (hex) Parameter Name.
514h Option parameter 1
515h Option parameter 2
516h Option parameter 3
517h Option parameter 4
518h Option parameter 5
519h Option parameter 6
51Ah Option parameter 7
51Bh Option parameter 8
Option parameter 9 - 44 N/A
Description
General settings, see "Parameter 1300 (514h, General
Settings)" on page 118
N/A
1
Network Type
2
Serial number (low word)
2
Serial number (high word)
Network specific 1, see "Parameter 1305 (519h, Device
address, node address)" on page 118
Network specific 2, see "Parameter 1306 (51Ah, Actual
device address, node address)" on page 118
Network specific 3, see "Parameter 1307 (51Bh, Option
board settings priority)" on page 119
Inverter Parameters
117
