18 • Vacon
5.1

Monitoring values

The monitoring values are the actual values of parameters and signals as well as statuses and
measurements. Monitoring values cannot be edited.

5.1.1 Monitoring 1

Code
V1.1.1 DC-Link Voltage
V1.1.2 DC-Link Ref.
V1.1.3 DC Voltage Ref.
V1.1.4 DC Voltage Act.
V1.1.5 Total Current
V1.1.6 Active Current
V1.1.7 Reactive Current
V1.1.8 Supply Frequency
V1.1.9 Supply Voltage
V1.1.10 Unit Temperature
V1.1.11 Status Word
V1.1.12 DIN 645. 321
V1.1.13 Analogue Input 1
V1.1.14 Analogue Input 2
V1.1.15 Analogue Out 1
V1.1.16 Operation Hours

5.1.2 FieldBus Monitoring values

Code Signal
V1.2.1 FB Control Word
V1.2.2 FB Status Word
V1.2.3 Fault Word 1
V1.2.4 Fault Word 2
V1.2.5 DIN Status Word 1
V1.2.6 DIN Status Word 2
V1.2.7 Warning Word 1
V1.2.8 DC Voltage
V1.2.9 Current
V1.2.10 Drive Power
V1.2.11 Fault History
V1.2.12 Final DC Ref
V1.2.13 Cabin State Word

5.1.3 Line Monitor OPT-D7

Code Signal
V1.3.1 Line Voltage
V1.3.2 Line Frequency
V1.3.3 Synch Error D7
V1.3.4 Line Voltage THD
V1.3.5 Line Voltage HF rms
Signal Unit
Vdc
Vdc
%
%
A
%
%
Hz
V
°C
%
%
%
h
Unit
kW
%
Unit
V
Hz
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
arfiff05 Standard AFE-II
ID Description
1108 Measured DC Link voltage in Volts, filtered.
25 DC Voltage Reference in Vdc
1200 Used DC Voltage Reference
7 Actual DC Voltage
Total current of the regenerative unit in
3
Amperes.
Avtive current of the regenerative drive in % of
Rated Line Current.
1125
> 0 power from AC side to DC side
< 0 power from DC side to AC side
Reactive current of the regenerative drive in % of
Rated Line Current.
1157
> 0 Inductive current
< 0 Capacitive current
Supply frequency in ##.## Hz .The sign indicates
1
the phase order.
6 Input AC voltage, RMS line to line Volts.
8 Heat sing temperature
43
15
13
14
26
1856
ID Description
1160 Control word from fieldbus
68 Status word to fieldbus
1172
1173
56
57
1174
44 Unfiltered DC-Link voltage
1113 Unfiltered total current
1508 Electrical AFE terminal power
37
1131
1884
ID Description
1650
1654
1659
1670
1671
