Vacon NX ACTIVE FRONT END II Applications Manual page 66

66 • Vacon
Control
On
Value
Control
Off
value
2 = Scale ABS Inverted
Inverted absolute value is scaled linearly between On and Off values.
Control
On
Value
Control
Off
value
3 = SR
Input value is used to make a step change in the output between On and Off values.
4 = Scale ABS
Input values is scaled linearly between On and Off values.
5 = Scale Inverted
Inverted value is scaled linearly between On and Off values
P2.9.1.8 Control Signal Filtering TC
This parameter is used to filter the scaling function output. This can be used, for
example, when unfiltered torque is used to control a parameter that needs stabilisation.
Off
Negative
On
value
value
Figure 2.
Off
Negative
On
value
value
Figure 3.
ID1586
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
arfiff05 Standard AFE-II
Off Positive On
value value
Off Positive On
value value
