Vacon NX ACTIVE FRONT END II Applications Manual page 24

24 • Vacon
V1.2.5 DIN Status 1
V1.2.6 DIN Status 2
DIN Status Word 1
b0 DIN: A.1
b1 DIN: A.2
b2 DIN: A.3
b3 DIN: A.4
b4 DIN: A.5
b5 DIN: A.6
b6 DIN: B.1
b7 DIN: B.2
b8 DIN: B.3
b9 DIN: B.4
b10 DIN: B.5
b11 DIN: B.6
b12 DIN: C.1
b13 DIN: C.2
b14 DIN: C.3
b15 DIN: C.4
V1.2.7 Warning Word 1
b0 Not used
b1 Temperature protection
b2
b3 Supply Phase Warning
b4 Not used
b5 Not used
Not used
b6
b7
Drive over temperature
Not used
b8
b9 Not used
Fan Warning
b10
b11 Not used
b12 Not used
b13 Not used
Not used
b14
b15 Not used
V1.2.8 DC Voltage
Unfiltered DC-Link Voltage
ID 56
ID57
DIN Status Word 2
DIN: C.5
DIN: C.6
DIN: D.1
DIN: D.2
DIN: D.3
DIN: D.4
DIN: D.5
DIN: D.6
DIN: E.1
DIN: E.2
DIN: E.3
DIN: E.4
DIN: E.5
DIN: E.6
ID 1174
Warning Word 1 ID1174
Fault
W29: Thermistor warning,
W56: FPT100 warning or
W71: LCL over temperature warning
W11
W14
W32: Fan Cooling
W70: LCL Fan monitor warning
[Vdc] ID44
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
arfiff05 Standard AFE-II
Fault Codes
