500 Vac Units Liquid-Cooled, 465-800 Vdc; 690 Vac Units Liquid-Cooled, 640-1100 Vdc - Vacon NX ACTIVE FRONT END II Applications Manual

Arfiff05 Standard AFE-II
2.3

500 Vac units Liquid-Cooled, 465-800 Vdc

Code Chassis
NXA01685A0T02WS
CH5
NXA02055A0T02WS CH5
NXA02615A0T02WS CH5
NXA03005A0T02WF CH61
NXA03855A0T02WF CH61
NXA04605A0T02WF CH62
NXA05205A0T02WF CH62
NXA05905A0T02WF CH62
NXA06505A0T02WF CH62
NXA07305A0T02WF CH62
NXA08205A0T02WF CH63
NXA09205A0T02WF CH63
NXA10305A0T02WF CH63
NXA11505A0T02WF CH63
NXA13705A0T02WF CH64
NXA16405A0T02WF CH64
NXA20605A0T02WF CH64
NXA23005A0T02WF CH64
2.4

690 Vac units Liquid-Cooled, 640-1100 Vdc

Code Chassis
NXA01706A0T02WF CH61
NXA02086A0T02WF CH61
NXA02616A0T02WF CH61
NXA03256A0T02WF CH62
NXA03856A0T02WF CH62
NXA04166A0T02WF CH62
NXA04606A0T02WF CH62
NXA05026A0T02WF CH62
NXA05906A0T02WF CH63
NXA06506A0T02WF CH63
NXA07506A0T02WF CH63
NXA08206A0T02WF CH64
NXA09206A0T02WF CH64
NXA10306A0T02WF CH64
NXA11806A0T02WF CH64
NXA13006A0T02WF CH64
NXA15006A0T02WF CH64
NXA17006A0T02WF CH64
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Ith [A] Il [A]
168 153
205 186
261 237
300 273
385 350
460 418
520 473
590 536
650 591
730 664
820 745
920 836
1030 936
1150 1045
1370 1245
1640 1491
2060 1873
2300 2091
Ith [A] Il [A]
170 155
208 189
261 237
325 295
385 350
416 378
460 418
502 456
590 536
650 591
750 682
820 745
920 836
1030 936
1180 1073
1300 1182
1500 1364
1700 1545
Ih [A]
112
137
174
200
257
307
347
393
433
487
547
613
687
767
913
1093
1373
1533
Ih [A]
113
139
174
217
257
277
307
335
393
433
500
547
613
687
787
867
1000
1133
vacon • 9
