Cabin State Di; Options - Vacon NX ACTIVE FRONT END II Applications Manual

Arfiff05 Standard AFE-II

7.3.3 Cabin State DI

P2.3.4.1 Main Fuse
P2.3.4.2 Aux Voltage
P2.3.4.3 STO Fuse
P2.3.4.4 Insulation Fault
P2.3.4.5 Earthswitch Fault
P2.3.4.6 Arc Relay
P2.3.4.7 High Amb. Temp
P2.3.4.8 Leakage

7.3.4 Options

P2.3.5.1 Stat/Stop Logic
Start Signal 1 ID 403 command
0 = Static
1 = Rising Edge
2 = Pulse
P2.3.5.2 Input Inversion
B00 = +1 = Inv. Open MCB (Force)
B01 = +2 = Inv. External Fault 1
B02 = +4 = Inv. External Fault 2
B03 = +8 = Inv. Enable MCB Close
B04 = +16 = Inv. MCB Trip input.
B05 = +32 = Inv. High Amb Temp.
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
ID1700
ID1703
ID1702
ID1704
ID1732
ID1733
ID1734
ID1735
ID300
ID1091
