50 • Vacon

7.4.2 Analogue outputs

P2.4.2.1 Iout 1 signal
Connect the AO signal to the analogue output of your choice with this parameter.
P2.4.2.2 Iout Content
0 = Not used
P2.4.2.3 Iout Filter Time ID308
Defines the filtering time of the analogue output signal. Setting this parameter value 0
will deactivate the filtering. First order filtering is used for the analogue output signals.
12000
10000
8000
6000
4000
2000
P2.4.2.4 Iout Invert
Inverts the analogue output signal:
•
Maximum output signal = Minimum set value.
•
Minimum output signal = Maximum set value.
ID464
ID307
0
ID309
100 %
Analogue
Output
0 %
0 %
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
arfiff05 Standard AFE-II
Unfiltered
1 s filter time
63 %
Function
100 %
Signal
