Fieldbus; Opt-D7 Protections; Options - Vacon NX ACTIVE FRONT END II Applications Manual

36 • Vacon

6.7.3 Fieldbus

Code Parameter
2.7.3.1 FB Fault Response
2.7.3.2 FB WD Delay
Table 5-9. Fieldbus Protections parameters G2.7.2

6.7.4 OPT-D7 protections

Code Parameter
2.7.4.1 THD Response
2.7.4.2 THD Warn. Limit
2.7.4.3 THD Fault Limit
2.7.4.4 HF rms Response
2.7.4.5 HF rms Warn Limit
2.7.4.6 HF rms Fault Limit
Table 5-9. OPT-D7 Protection parameters G2.7.3

6.7.5 Options

Code Parameter
2.7.5 Fault Simulation
2.7.6 Reset Datalogger
Table 5-9. Options parameters G2.7.2
Min Max Unit
0 2
0,00 30,00
Min Max Unit
0 2
0,00 50,00 %
0,00 50,00 %
0 2
0,0 400,0 V
0 400,0 V
Min Max Unit
0 65535
0 1
