2.

AFE UNITS

Air and liquid-cooled products listed in chapter 2 are compatible with AFE application ARFIFF05.
Hardware and software support for AFE use is only available for these products.
Downloading AFE application to products other than those listed in chapter 2 is considered to be a
non-standard product which functionality has not been verified or documented. In such cases User
takes full responsibility for possible hardware and software problems. Application support is not
available for non-standard products.
2.1

500 Vac units Air Cooled, 465-800 Vdc

Code
NXA_0168 5 A0T02SG
NXA_0205 5 A0T02SG
NXA_0261 5 A0T02SG
NXA_0385 5 A0T02SG
NXA_0460 5 A0T02SG
NXA_1150 5 A0T02SG
NXA_1300 5 A0T02SG
2.2

690 Vac units Air Cooled, 640-1100 Vdc

Code
NXA_0125 6 A0T02SG
NXA_0144 6 A0T02SG
NXA_0170 6 A0T02SG
NXA_0261 6 A0T02SG
NXA_0325 6 A0T02SG
NXA_0920 6 A0T02SG
NXA_1030 6 A0T02SG
Frame IL-cont [A]
FI9 170
FI9 205
1xFI9 261
1xFI10 385
1xFI10 460
1xFI13 1150
1xFI13 1300
Frame IL-cont [A]
1xFI9 125
1xFI9 144
1xFI9 170
1xFI10 261
1xFI10 325
1xFI13 920
1xFI13 1030
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
arfiff05 Standard AFE-II
IH-cont
[A]
140
170
205
300
385
1030
1150
IH-cont
[A]
100
125
144
208
261
820
920
