- Page 1 ® ac drives ip54 kit installation manual...
-
Page 3: Table Of Contents
2 • vacon INDEX General..........................3 Vacon IP54 kit contents ...................... 3 FR4 (Type designation code: NXIP54FR4) .................. 3 FR5 (Type designation code: NXIP54FR5) .................. 4 FR6 (Type designation code: NXIP54FR6) .................. 4 Installation ......................... 5 Installation instructions #1 ......................5... -
Page 4: General
Figure 1. Contents of IP54 kit for FR4 IP54 enclosure for FR4 Plastic sealing IP54 cable cover with fan Screws (4x10) Cable entry flange with rubber grommets Warning sticker Cable extension for fan 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com... - Page 5 4 • vacon Vacon IP54 kit contents FR5 (Type designation code: NXIP54FR5) Figure 2. Contents of IP54 kit for FR5 IP54 enclosure for FR5 Rubber sealings IP54 cable cover with fan Screws (4x10) Cable entry flange with rubber grommets Warning sticker...
-
Page 6: Fr4 (Type Designation Code: Nxip54Fr4)
6. Fix the IP54 lid with fan (#2) on 7. Open the control cable cover ber sealings (#4). Leave the open- the power unit cover. and remove the cable entry flange. ing uncovered. 24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com... - Page 7 6 • vacon Installation 8. Remove the power cable cover 9. Take the IP54 cable cover and 10. Use the attached screws to fix connect the fan power cable to and detach the grounding rack the IP54 cable cover with fan and connector marked with 'FAN' the grounding rack.
-
Page 8: Information Sticker
Dri ve m odified : Option board: NXOPT ....Date:....in slot: IP54 upgrade/ Collar Date:....EMC level modified: H to T / T to H Date:....24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com... - Page 10 Document ID: Vacon Ltd Member of the Danfoss Group Rev. A Runsorintie 7 65380 Vaasa Finland...
