38 • Vacon
6.9

ID Control Functions

6.9.1 Value control

Code Parameter
Control Input Signal
P2.9.1.1
ID
Control Input Off
P2.9.1.2
Limit
Control Input On
P2.9.1.3
Limit
Control Output Off
P2.9.1.4
Value
Control Output On
P2.9.1.5
Value
Control Output Signal
P2.9.1.6
ID
P2.9.1.7 Control Mode
Control Output
P2.9.1.8
Filtering rime

6.9.2 DIN ID Control 1

Code Parameter
P2.9.2.1 ID Control DIN
P2.9.2.2 Controlled ID
P2.9.2.3 False value
P2.9.2.4 True value
Table 1. Power reference input signal selection, G2.2.8
Min Max Unit
0 10000 ID
-32000 32000
-32000 32000
-32000 32000
-32000 32000
0 10000 ID
0 5
0.000 32.000 s
Table 2. DIN ID control parameters, G2.2.8
Min Max Unit
0.1 E.10
0 10000 ID
-32000 32000
-32000 32000
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
arfiff05 Standard AFE-II
Default Cust ID
0 1580
0 1581
0 1582
0 1583
0 1584
0 1585
0 1586
0.000 1721
Default Cust ID
0.1 1570
0 1571
0 1572
0 1573
Description
0 = SR ABS
1 = Scale ABS
2 = Scale INV ABS
3 = SR
4 = Scale
5 = Scale INV
Description
Slot Board input No.
If 0.1 ID61 can be
controlled from FB
Select ID that is
controlled by digital input
Value when DI is low
Value when DI is high
