Vacon Afe 1 Profile (2) - Vacon NX ACTIVE FRONT END II Applications Manual

Arfiff05 Standard AFE-II

8.2.2 Vacon AFE 1 profile (2)

Signal
B00 DC Charge
B01
B02
B03 Run
B04
B05
B06
B07 Reset
B08 DC Voltage Ref B00
B09 DC Voltage Ref B01
B10 Fieldbus Control
B11
Watchdog
B12 FB DIN2
B13 FB DIN3
FB DIN4
B14
B15
B00: FALSE = Open MCB, TRUE = PreCharge DC
Open MCB: Opens MCB if closed, stops precharging if not closed.
PreCharge DC: Drive will start precharge if function activated by digital output and control place is
fieldbus. When control place is not fieldbus precharging is started from normal start command.
B03: FALSE = Stop Request, TRUE = Start Request
Stop Request: Drive will stop .
Start Request: Start Command to the drive. Rising edge needed for start.
B07: FALSE = No significance, TRUE = Fault Acknowledge
Fault Acknowledge: The group signal is acknowledged with a positive edge.
B08: FALSE = No Function, TRUE = DC Ref 1
B09: FALSE = No Function, TRUE = DC Ref 2
DC Ref FB Reference
B08 FALSE
B09 FALSE
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
FB Control Word ID1160
0= Open MCB.
1= Close DC charge contactor, MCB closed automatically.
0= AFE is stopped
1= AFE is started
0>1 Reset fault.
B00 | B01
0 | 0 = FB Reference. P2.2.1, if not FB Control & FB Ref > 50,00 %
0 | 1 = 110 %
1 | 0 = 115 %
1 | 1 = 120 %
0= No control from fieldbus
1=Control from fieldbus
0,5 sec square wave clock. This is used to check data
communication between fieldbus master and the drive.
Can be used to control RO or directly parameter by ID number. G2.4.1
Can be used to control RO or directly parameter by ID number. G2.4.1
Can be used to control RO or directly parameter by ID number. G2.4.1
Reserved for future use.
110,00 %
TRUE
FALSE
Comment
115,00 %
FALSE
TRUE
vacon • 71
120,00 %
TRUE
TRUE
