Drive Control Parameters; Control - Vacon NX ACTIVE FRONT END II Applications Manual

34 • Vacon
6.6

Drive Control parameters

Code Parameter
P2.6.1 AFE Options 1
P2.6.2 AFE Options 2
P2.6.3 Control Options
P2.6.4 Start Delay
P2.6.5 Modulator Type
P2.6.6 Operation Time
Table 5-6. Drive control parameters G2.4

6.6.1 Control

Code Parameter
P2.6.7.1 Capacitor Size
P2.6.7.2 Inductor Size
P2.6.7.3 Dynamic Support Kp
P2.6.7.4 Synch Kp
P2.6.7.5 Synch Ti
P2.6.7.6 Active Current Kp
P2.6.7.7 Active Current Ti
P2.6.7.8 Synch. Kp Start
P2.6.7.9 Voltage Ctrl Kp
P2.6.7.10 Voltage Ctrl Ti
P2.6.7.11 Switching Frequency
Table 5-6. Drive control parameters G2.4
Min Max Unit
0 65535
0 65535
0 65536
0,00 320,00 s
0 4
0 2^32
Min Max Unit
0 100 %
0 100 %
0 32000
0 32000
0 1000
0 4000
0,0 100,0
0 10000
0 32000
0 1000 ms
3,4 Varies Hz
