Vacon NX ACTIVE FRONT END II Applications Manual page 49

Arfiff05 Standard AFE-II
P2.4.1.10 Ready To Start
Drive is ready for charge and start command. No active fault or warnings.
P2.4.1.11 FB Dig Input 1
P2.4.1.13 FB Dig Input 2
P2.4.1.15 FB Dig Input 3
P2.4.1.17 FB Dig Input 4
P2.4.1.19 FB Dig Input 5
The data from the fieldbus main control word can be led to the digital outputs of the
drive. See the fieldbus board manual for the location of these bits.
P2.4.1.12 FB Dig 1 Input Par
P2.4.1.14 FB Dig 2 Input Par
P2.4.1.16 FB Dig 3 Input Par
P2.4.1.18 FB Dig 4 Input Par
P2.4.1.20 FB Dig 5 Input Par
With these parameters you can define the parameter to be controlled by using FB digital
input.
Example:
All option board inputs are already in use, but you want to give a DI: External Fault 1
(ID405) and drive has a fieldbus board.
Set parameter ID892 (Fieldbus Digital Input 2) to 405. Now you are able to control
External Fault 1 command from the fieldbus by Profibus control word (bit 11).
It is possible to control any parameter in the same way if values 0 = FALSE and 1 = TRUE
are significant for that parameter. For example, P2.1.5 Parallel AFE (ID1501) can be
switched on and off using this function (Parallel AFE: 0 = No, 1 = Yes).
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
455
456
457
169
170
891
892
893
894
895
vacon • 49
