Status And Control Words In Detail; Basic In Bypass (0) - Vacon NX ACTIVE FRONT END II Applications Manual

Arfiff05 Standard AFE-II
8.

STATUS AND CONTROL WORDS IN DETAIL

P2.10.19 State machine
0 / Basic
1 / Standard
2 / Vacon AFE 1
3 / Vacon AFE 2
8.1

Basic In ByPass (0)

Signal
0= AFE is stopped
Run
B00
1= AFE is started
B01
Fault Reset
B02 0>1 Reset fault.
B03
FB DIN1
Can be used to control RO or directly parameter by ID number. G2.4.1
B04 FB DIN2 Can be used to control RO or directly parameter by ID number. G2.4.1
B05
FB DIN3 Can be used to control RO or directly parameter by ID number. G2.4.1
B06 FB DIN4 Can be used to control RO or directly parameter by ID number. G2.4.1
B07 FB DIN5 Can be used to control RO or directly parameter by ID number. G2.4.1
B08
B09
B10
B11
B12
B13
B14
B15
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
This mode makes fieldbus control behave as in explained in used
fieldbus board manual.
Simple control word that is used in modes where control word
from fieldbus is used as such, for some fieldbus board this
requires bypass operation.
This mode uses ProfiDrive type state machine in application level.
This mode is possible to use on fieldbus boards that does not have
state machine itself or has possibility to bypass state machine
functionality in option board.
This mode uses ProfiDrive type state machine in application level.
This mode is possible to use on fieldbus boards that does not have
state machine itself or has possibility to bypass state machine
functionality in option board.
FB Control Word ID1160
Description
vacon • 69
