Vacon NX ACTIVE FRONT END II Applications Manual page 23

Arfiff05 Standard AFE-II
V1.2.3 Fault Word 1
b0 Over Current
b1
Overvoltage
Under voltage
b2
b3
Not used
b4 Earth Fault
b5 Not used
b6
Unit Over Temperature
Over Temperature
b7
b8 Input Phase loss
b9 Not used
b10 Device Fault
b11
Not used
b12
Not used
b13 Not used
b14 Not used
b15
Not used
V1.2.4 Fault Word 2
b0
Not used
Charging Switch Fault
b1
b2
Not used
b3 Drive Hardware fault
b4 Under Temperature
b5
EPROM or Checksum fault
External fault
b6
b7
Not used
b8 Internal Communication
b9 IGBT Temperature
b10
Not used
Cooling fan
b11
b12 Application fault
b13 Drive Internal fault
MCB State
b14
b15 Not used
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
ID 1172
Fault Word 1 ID1172
Fault
F1
F2
F9
F3
F14
F59, F56,F71
F11
F37, F38, F39, F40, F44, F45
ID 1173
Fault Word 2 ID1173
Fault
F5, F80
F4, F7
F13
F22
F51
F25
F31, F41
F32, F70
F35
F33, F36, F8, F26
F64
Fault Codes
Fault Codes
vacon • 23
