Arfiff05 Standard AFE-II
6.3

Input signals

6.3.1 Digital inputs

Code Parameter
P2.3.1.1 Start Signal 1
P2.3.1.2 Enable MCB Close
Open MCB Power
P2.3.1.3
Dawn
P2.3.1.4 LCL Temp. X51
P2.3.1.5 LCL Temp. X52
P2.3.1.6 MCB Status
P2.3.1.7 Run Enable
P2.3.1.8 Quick Stop
P2.3.1.9 Ext. Fault 1
P2.3.1.10 Ext. Fault 2
P2.3.1.11 Fault Reset
P2.3.1.12 LC Cooling
P2.3.1.13 MCB Trip State
Table 5-3. Digital inputs parameters

6.3.2 Analogue Input 1

Code Parameter
P2.4.3.1 AI1 signal selection
P2.4.3.2 AI1 filter time
AI1 custom
P2.4.3.3
minimum setting
AI1 custom
P2.4.3.4
maximum setting
P2.4.3.5 AI1 signal inversion
AI1 reference
P2.4.3.6 scaling, minimum
value
AI1 reference
P2.4.3.7 scaling, maximum
value
P2.4.3.8 AI1 Controlled ID
Table 1- 2, ANALOG INPUT1,

6.3.3 Analogue Input 2

Code Parameter
P2.4.4.1 AI2 signal selection
P2.4.4.2 AI2 filter time
AI2 custom
P2.4.4.3
minimum setting
AI2 custom
P2.4.4.4
maximum setting
P2.4.4.5 AI2 signal inversion
AI2 reference
P2.4.4.6 scaling, minimum
value
AI2 reference
P2.4.3.7 scaling, maximum
value
P2.4.4.8 AI2 Controlled ID
Table 1- 3, ANALOG INPUT2
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Min Max Unit
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn:
0.1 E.10 DigIn
Min Max Unit
0.1 E.10 AnIN:
0,000 32,000 s
-160,00 160,00 %
-160,00 160,00 %
0 1
-32000 32000
-32000 32000
0 10000
Min Max Unit
0.1 E.10 AnIN:
0,000 32,000 s
-160,00 160,00 %
-160,00 160,00 %
0 1
-32000 32000
-32000 32000
0 10000
Default ID
A.1 403
With CO.B00; Opens MCB
0.2 1619
also
0.2 1600 Power down command
0.2 1179
0.2 1125
A.4 1453
0.2 407
Power down with a
0.2 1213
warning
0.1 405
0.1 406
0.1 414
0.2 750
0.1 1706
Default ID Note
0.1 377
0,000 324
0,00 321
100,00 322
0 387
0 303
0 304
0 1507
Default ID Note
0.1 388
0,000 329
0,00 326
100,00 327
0 398
0 393
0 394
0 1511
