Start Here - ProSoft MVI56E-MCMR User Manual

MVI56E-MCMR ♦ ControlLogix Platform
Modbus Communication Module with Reduced Data Block
1

Start Here

In This Chapter

What's New? ......................................................................................... 10

System Requirements ........................................................................... 11

Deployment Checklist ............................................................................ 12

Package Contents ................................................................................. 14

Setting Jumpers .................................................................................... 15

Installing the Module in the Rack ........................................................... 16

Importing the Sample Add-On Instruction.............................................. 18

Creating a New RSLogix 5000 Project .................................................. 19

Connecting Your PC to the ControlLogix Processor .............................. 40

Downloading the Sample Program to the Processor ............................. 41
To get the most benefit from this User Manual, you should have the following
skills:

Rockwell Automation
ladder logic, and transfer the ladder logic to the processor

Microsoft Windows: install and launch programs, execute menu commands,
navigate dialog boxes, and enter data

Hardware installation and wiring: install the module, and safely connect
MCMR and ControlLogix devices to a power source and to the MVI56E-
MCMR module's application port(s)
ProSoft Technology, Inc.
RSLogix™ software: launch the program, configure
®
Start Here
User Manual
Page 9 of 223
