This user manual explains the features of the MVI56E-61850C module and guides you
through the installation and configuration of the module. This includes using the ProSoft
MVI56E-61850C Configuration Manager software to map data for Intelligent Electronic
Devices (IEDs) on the IEC 61850 network for use with a Rockwell Automation
ControlLogix
®
5000 Logix Designer programming software, simplifying the integration of the module
into your system.
The high-level steps for the process of configuring the IEC 61850 network are as follows:
1 Add the MVI56E-61850C to your Studio 5000 Logix Designer project. See
the Module to Studio 5000 Logix Designer
2 Configure the module Ethernet settings through the Add-On Profile. See
the MVI56E-61850C Add-On Profile"
3
Launch the ProSoft MVI56E-61850C Configuration Manager and take the following
steps to configure client functionality:
a
Import the IED configuration files (CID or SCD files). See
Configuration Files"
b Add the IEDs to the IEC 61850 network. See
page 28.
c
Map the desired data attributes for each IED. See
IEDs" on page 30.
4 Configure GOOSE Publish (server) functionality (if applicable). See
GOOSE Publish"
5 Export the configuration to the MVI56E-61850C Add-On Profile. See
Configuration to the Add-On Profile"
6
Import the MVI56E-61850C Program into Studio 5000 Logix Designer. See
the MVI56E-61850C Program into Studio 5000 Logix Designer"
