Ladder Logic
User Manual
MCMRBlockStats
The MCMRB
LOCK
MVI56E-MCMR module.
Name
Read
Write
Parse
Event
Cmd
Err
Command Control Data Object (MCMRCONTROL)
Contains the data structure required for the processor to request special tasks
from the module. The command control task allows the processor to dynamically
enable commands configured in the port command list. The event command task
allows the processor to dynamically build any commands to be sent by the
module Master port to a remote Slave.
The following table describes the structure of this object.
Name
ColdBoot
WarmBoot
CmdControlP1
CmdControlP2
EventTriggerP1
EventTriggerP2
EventCmdP1
EventCmdP2
EventCmdRespP1
EventCmdRespP2
Page 118 of 223
S object stores the block transfer statistics for the
TATS
Data Type
INT
INT
INT
INT
INT
INT
Data Type
BOOL
BOOL
MCMRCmdControl
MCMRCmdControl
BOOL
BOOL
MCMREventCmd[100]
MCMREventCmd[100]
INT[5]
INT[5]
MVI56E-MCMR ♦ ControlLogix Platform
Modbus Communication Module with Reduced Data Block
Description
Total number of read block transfers
Total number of write block transfers
Total number of blocks parsed
Total number of event blocks received
Total number of command blocks received
Total number of block transfer errors
Description
Triggers a Cold Boot Command
Triggers a Warm Boot Command
Command Control for Port 1
Command Control for Port 2
Triggers the Event Command.
Triggers the Event Command.
This object contains the attributes to define a
Master command. An array of these objects
is used for each port.
This object contains the attributes to define a
Master command. An array of these objects
is used for each port.
Event Command Response for Port 1
Event Command Response for Port 2
