MVI56E-MCMR ♦ ControlLogix Platform
Modbus Communication Module with Reduced Data Block
Offset Content
16 Port 2 Command List
Requests
17 Port 2 Command List
Response
18 Port 2 Command List
Errors
19 Port 2 Requests
20 Port 2 Responses
21 Port 2 Errors Sent
22 Port 2 Errors
Received
23 Read Block Count
24 Write Block Count
25 Parse Block Count
26 Command Event
Block Count
27 Command Block
Count
28 Error Block Count
29 Port 1 Current Error
30 Port 1 Last Error
31 Port 2 Current Error
32 Port 2 Last Error
ProSoft Technology, Inc.
Description
This field contains the number of requests made from this
port to Slave devices on the network.
This field contains the number of Slave response messages
received on the port.
This field contains the number of command errors processed
on the port. These errors could be due to a bad response or
command.
This field contains the total number of messages sent out the
port.
This field contains the total number of messages received on
the port.
This field contains the total number of message errors sent
out the port.
This field contains the total number of message errors
received on the port.
This field contains the total number of read blocks
transferred from the module to the processor.
This field contains the total number of write blocks
transferred from the module to the processor.
This field contains the total number of blocks successfully
parsed that were received from the processor.
This field contains the total number of command event
blocks received from the processor.
This field contains the total number of command blocks
received from the processor.
This field contains the total number of block errors
recognized by the module.
For a Slave port, this field contains the value of the current
error code returned. For a Master port, this field contains the
index of the currently executing command.
For a Slave port, this field contains the value of the last error
code returned. For a Master port, this field contains the index
of the command with the error.
For a Slave port, this field contains the value of the current
error code returned. For a Master port, this field contains the
index of the currently executing command.
For a Slave port, this field contains the value of the last error
code returned. For a Master port, this field contains the index
of the command with an error.
Verify Communication
