MVI69E-MBS ♦ CompactLogix Platform
Modbus Serial Enhanced Communication Module
1

Start Here

In This Chapter

System Requirements ........................................................................... 10

Deployment Checklist ............................................................................ 10

Package Contents ................................................................................. 11

Setting Jumpers .................................................................................... 12

Installing the Module in the Rack ........................................................... 13
To get the most benefit from this User Manual, you should have the following
skills:

Rockwell Automation
ladder logic, and transfer the ladder logic to the processor

Microsoft Windows
commands, navigate dialog boxes, and enter data

Hardware installation and wiring: install the module, and safely connect
Modbus and CompactLogix or MicroLogix 1500-LRP devices to a power
source and to the MVI69E-MBS module's application port(s)
ProSoft Technology, Inc.
June 28, 2017
RSLogix™ software: launch the program, configure
®
®
: install and launch programs, execute menu
Start Here
User Manual
Page 9 of 154
