ProSoft MVI56E-MCMR User Manual page 55

MVI56E-MCMR ♦ ControlLogix Platform
Modbus Communication Module with Reduced Data Block
The following parameters are displayed when the Type parameter is set to
M .
ASTER
The following table describes the parameters in the E
dialog box when the Type parameter is set to M
Parameter
Enabled
Type
Protocol
Baud Rate
Parity
Data Bits
Stop Bits
RTS On
RTS Off
Use CTS Line
ProSoft Technology, Inc.
Description
1 = , 0 = disable port
ENABLE PORT
0 = M , 1 = Slave
ASTER
0 = M RTU , 1 = Modbus ASCII mode
ODBUS MODE
Sets the baud rate for the port. Valid values for this field are 110, 150,
300, 600, 1200, 2400, 4800, 9600, 19200, 384 or 3840 (for 38,400
baud), 576 or 5760 (for 57,600 baud) and 115,1152, or 11520 (for
115,200 baud)
0 = None, 1 = Odd, 2 = Even
Modbus RTU mode = 8 Modbus ASCII mode = 8 or 7
Valid values are 1 or 2.
0 to 65535 milliseconds to delay after RTS line is asserted on the port
before data message transmission begins. This delay can be used to
allow for radio keying or modem dialing before data transmission
begins.
0 to 65535 milliseconds to delay after data message is complete
before RTS line is dropped on the port.
N or Y
O ES
This parameter is used to enable or disable hardware handshaking.
The default setting is N hardware handshaking, CTS Line not used.
O
Set to N if the connected devices do not need hardware
O
handshaking. Set to Y if the device(s) connected to the port require
ES
hardware handshaking (most modern devices do not). If you set this
parameter to Y , be sure to pay attention to the pinout and wiring
ES
requirements to ensure that the hardware handshaking signal lines are
properly connected; otherwise communication will fail.
Configuring the MVI56E-MCMR Module
– M
P
DIT ODBUS
.
ASTER
User Manual
1
ORT
Page 55 of 223
