Configuring The Mvi56E-Mcmr Module; Installing Prosoft Configuration Builder - ProSoft MVI56E-MCMR User Manual

MVI56E-MCMR ♦ ControlLogix Platform
Modbus Communication Module with Reduced Data Block
2

Configuring the MVI56E-MCMR Module

In This Chapter


Installing ProSoft Configuration Builder ................................................. 45


Using ProSoft Configuration Builder Software ....................................... 46

Configuration as a Modbus Master ........................................................ 52

Configuration as a Modbus Slave .......................................................... 78

Ethernet Configuration .......................................................................... 87

Connecting Your PC to the Module's Ethernet Port ............................... 88

Downloading the Project to the Module ................................................. 92
2.1 Installing ProSoft Configuration Builder
The ProSoft Configuration Builder (PCB) software is used to configure the
module. You can find the latest version of the ProSoft Configuration Builder
(PCB) on our web site: http://www.prosoft-technology.com. The installation
filename contains the PCB version number. For example,
PCB_4.1.0.4.0206.
1 Open a browser window and navigate to
http://www.prosoft-technology.com/pcb.
2 Click the download link for ProSoft Configuration Builder, and save the file to
your Windows desktop.
3 After the download completes, double-click on the PCB installation file, and
follow the instructions that appear on the screen.
4 If you want to find additional software specific to your MVI56E-MCMR, enter
the model number into the website search box and press the Enter key.
