Configuring the MVI56E-MCMR Module
User Manual
The module's default IP address is 192.168.0.250. Choose an unused IP
5
within your subnet, and then click OK.
Important: The temporary IP address is only valid until the next time the module is initialized. For
information on how to set the module's permanent IP address, see Ethernet Configuration (page
87).
6 Close the ProSoft Discovery Service window. Enter the temporary IP in the
Ethernet address field of the Connection Setup dialog box, then click the
T C
EST ONNECTION
current settings.
Page 90 of 223
Modbus Communication Module with Reduced Data Block
button to verify that the module is accessible with the
MVI56E-MCMR ♦ ControlLogix Platform
ProSoft Technology, Inc.
