ProSoft PTQ-LNG User Manual

Quantum / unity platform landis & gyr telegyr interface module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PTQ-LNG
Quantum / Unity Platform
Landis & Gyr Telegyr Interface Module

User Manual

May 29, 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTQ-LNG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProSoft PTQ-LNG

Summary of Contents for ProSoft PTQ-LNG

  • Page 1: User Manual

    PTQ-LNG Quantum / Unity Platform Landis & Gyr Telegyr Interface Module User Manual May 29, 2007...

  • Page 2: Please Read This Notice

    Successful application of this module requires a reasonable working knowledge of the Schneider Electric Quantum / Unity hardware, the PTQ-LNG Module and the application in which the combination is to be used. For this reason, it is important that those responsible for implementation satisfy themselves that the combination will meet the needs of the application without exposing personnel or equipment to unsafe or inappropriate working conditions.

  • Page 3: Table Of Contents

    Contents PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Contents PLEASE READ THIS NOTICE......................2 Important Notice:...........................2 Your Feedback Please ........................2 START HERE ..........................5 Hardware and Software Requirements ...............5 1.1.1 ProTalk Module Carton Contents ..................5 CONFIGURING THE PROCESSOR WITH CONCEPT ..............7 Information for Concept Version 2.6 Users ..............7...
  • Page 4 PTQ-LNG ♦ Quantum / Unity Platform Contents Landis & Gyr Telegyr Interface Module DIAGNOSTICS AND TROUBLESHOOTING................65 Reading Status Data From the Module ..............65 7.1.1 The Configuration/Debug Menu .................. 65 7.1.2 Required Hardware ..................... 66 7.1.3 Required Software....................... 66 7.1.4...

  • Page 5: Start Here

    Start Here PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Start Here In This Chapter Hardware and Software Requirements ........5 This guide is intended to guide you through the ProTalk module setup process, from removing the module from the box to exchanging data with the processor. In...
  • Page 6 PTQ-LNG ♦ Quantum / Unity Platform Start Here Landis & Gyr Telegyr Interface Module 1454-9F DB-9 Female to 5 Pos Screw Terminal ProSoft Solutions CD Adapter (Serial protocol modules only) Note: The DB-9 Female to 5 Pos Screw Terminal Adapter is not required on Ethernet modules and is therefore not included in the carton with these types of modules.

  • Page 7: Configuring The Processor With Concept

    Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Configuring the Processor with Concept In This Chapter Information for Concept Version 2.6 Users ......7 Create a New Project ............... 9 Add the PTQ Module to the Project........12 Set up Data Memory in Project ..........
  • Page 8 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module This action opens the Concept Module Installation dialog box. Choose File → Open Installation File. This action opens the Open Installation File dialog box: If you are using a Quantum processor, you will need the MDC files.

  • Page 9: Create A New Project

    Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Select the files that go with the Concept version you are using, and then click OK. This action opens the Add New Modules dialog box.
  • Page 10 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module Open the File menu, and then choose New Project. This action opens the PLC Configuration dialog box. In tIn the list of options on the left side of this dialog box, double-click the PLC Selection folder.
  • Page 11 Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module In the CPU/Executive pane, use the scroll bar to locate and select the PLC to configure. Click OK. This action opens the PLC Configuration dialog box, populated with the correct values for the PLC you selected.

  • Page 12: Add The Ptq Module To The Project

    PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module Make a note of the holding registers for the module. You will need this information when you modify your application as outlined in the ProTalk Application Reference Guides.
  • Page 13 Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Click the Edit button to open the Local Quantum Drop dialog box. This dialog box is where you identify rack and slot locations.
  • Page 14 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module In the Modules pane, use the scroll bar to locate and select the ProTalk module, and then click OK. This action copies the description of the ProTalk module next to the assigned rack and slot number of the Local Quantum Drop dialog box.

  • Page 15: Set Up Data Memory In Project

    Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Set up Data Memory in Project In the list of options on the left side of the PLC Configuration dialog box, double-click Specials.
  • Page 16 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module Selecting the Time of Day Select (check) the Time of Day box, and then enter the value 00001 as shown in the following example. This value sets the first time of day register to 400001.

  • Page 17: Download The Project To The Processor

    Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module This action opens the Save Project As dialog box. Name the project, and then click OK to save the project to a file.
  • Page 18 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module In the PLC Configuration dialog box, open the Online menu, and then choose Connect. This action opens the Connect to PLC dialog box.

  • Page 19: Verify Successful Download

    Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Click All, and then click Download. If a message box appears indicating that the controller is running, click Yes to shut down the controller. The Download Controller dialog box displays the status of the download as shown in the following illustration.
  • Page 20 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module In the PLC Configuration window, open the Online menu, and then choose Online Control Panel. This action opens the Online Control Panel dialog box.
  • Page 21 Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Place the cursor over the first address field, as shown in the following illustration. In the PLC Configuration window, open the Templates menu, and then choose Insert Addresses.
  • Page 22 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module Notice that the template populates the address range, as shown in the following illustration. Place your cursor as shown in the first blank address field below the addresses you just entered.
  • Page 23 Configuring the Processor with Concept PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module 11 In the PLC Configuration window, open the Online menu, and then choose Animate. This action opens the RDE Template dialog box, with animated values in the Value field.
  • Page 24 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with Concept Landis & Gyr Telegyr Interface Module Page 24 of 103 ProSoft Technology, Inc. May 29, 2007...

  • Page 25: Configuring The Processor With Proworx

    Configuring the Processor with ProWORX PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Configuring the Processor with ProWORX When you use ProWORX 32 software to configure the processor, using the example SAF file provided on the ProTalk Solutions CD-ROM will be required.
  • Page 26 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with ProWORX Landis & Gyr Telegyr Interface Module Select the .SAF File that is located at the CD-ROM shipped with the PTQ module. After you click on Open you should see the PTQ modules imported (select...
  • Page 27 Configuring the Processor with ProWORX PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Now you can close the Schneider Alliances application and run the Proworx 32 software. At the Traffic Cop section, select the PTQ module to be inserted at the slot: ProSoft Technology, Inc.
  • Page 28 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with ProWORX Landis & Gyr Telegyr Interface Module Page 28 of 103 ProSoft Technology, Inc. May 29, 2007...

  • Page 29: Configuring The Processor With Unitypro Xl

    Configuring the Processor with UnityPro XL PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Configuring the Processor with UnityPro XL In This Chapter Create a New Project ............. 29 Add the PTQ Module to the Project........31 Build the Project ..............
  • Page 30 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with UnityPro XL Landis & Gyr Telegyr Interface Module The next step is to add a power supply to the project. In the Project Browser, expand the Configuration folder, and then double-click the 1:LocalBus icon.

  • Page 31: Add The Ptq Module To The Project

    Configuring the Processor with UnityPro XL PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Expand the Supply folder, and then select your power supply from the list. Click OK to continue. Repeat these steps to add any additional devices to your Quantum Rack.

  • Page 32: Build The Project

    PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with UnityPro XL Landis & Gyr Telegyr Interface Module Next, enter the module personality value. The correct value for ProTalk modules is 1060 decimal (0424 hex). Before you can save the project in UnityProXL, you must validate the modifications.

  • Page 33: Connect Your Pc To The Processor

    Configuring the Processor with UnityPro XL PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module As the project is built, Unity Pro XL reports its process in a Progress dialog box, with details appearing in a pane at the bottom of the window. The following illustration shows the build process under way.
  • Page 34 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with UnityPro XL Landis & Gyr Telegyr Interface Module To verify address and driver settings in UnityPro XL: Open the PLC menu, and choose Standard Mode. This action turns off the PLC Simulator, and allows you to communicate directly with the Quantum or Unity hardware.

  • Page 35: Connecting To The Processor With Tcpip

    Configuring the Processor with UnityPro XL PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Click the Driver Settings button to open the SCHNEIDER Drivers management Properties dialog box. Click the Install/update button to specify the location of the Setup.exe file containing the drivers to use.

  • Page 36: Download The Project To The Processor

    PTQ-LNG ♦ Quantum / Unity Platform Configuring the Processor with UnityPro XL Landis & Gyr Telegyr Interface Module Click the Test Connection button to verify that your settings are correct. The next step is to download the Project to the Processor.

  • Page 37: Setting Up The Protalk Module

    Setting Up the ProTalk Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Setting Up the ProTalk Module In This Chapter Install the ProTalk Module in the Quantum Rack ....37 Connect the PC to the ProTalk Configuration/Debug Port ..43 After you complete the following procedures, the ProTalk module will actively be transferring data bi-directionally with the processor.

  • Page 38: Inserting The 1454-9F Connector

    PTQ-LNG ♦ Quantum / Unity Platform Setting Up the ProTalk Module Landis & Gyr Telegyr Interface Module 5.1.2 Inserting the 1454-9F connector Insert the 1454-9F connector as shown. Wiring locations are shown in the table: 5.1.3 Install the ProTalk Module in the Quantum Rack Place the Module in the Quantum Rack.

  • Page 39: Cable Connections

    5.1.4 Cable Connections The application ports on the PTQ-LNG module support RS-232, RS-422, and RS-485 interfaces. Please look at the module to ensure that the jumpers are set correctly to correspond with the type of interface you are using.
  • Page 40 PTQ-LNG ♦ Quantum / Unity Platform Setting Up the ProTalk Module Landis & Gyr Telegyr Interface Module RS-232 Configuration/Debug Port This port is physically a DB-9 connection. This port permits a PC based terminal emulation program to view configuration and status data in the module and to control the module.
  • Page 41 Setting Up the ProTalk Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module RS-232 -- Modem Connection This type of connection is required between the module and a modem or other communication device. The "Use CTS Line" parameter for the port configuration should be set to 'Y' for most modem applications.
  • Page 42 PTQ-LNG ♦ Quantum / Unity Platform Setting Up the ProTalk Module Landis & Gyr Telegyr Interface Module RS-232 -- Null Modem Connection (No Hardware Handshaking) This type of connection can be used to connect the module to a computer or field device communication port.

  • Page 43: Connect The Pc To The Protalk Configuration/Debug Port

    Setting Up the ProTalk Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module RS-422 RS-485 and RS-422 Tip If communication in the RS-422/RS-485 mode does not work at first, despite all attempts, try switching termination polarities. Some manufacturers interpret +/- and A/B polarities differently.
  • Page 44 PTQ-LNG ♦ Quantum / Unity Platform Setting Up the ProTalk Module Landis & Gyr Telegyr Interface Module In the HyperTerminal window, enter a connection name, for example Test, and then click OK. This action opens the Connect To dialog box.
  • Page 45 Setting Up the ProTalk Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Verify that the settings match those shown in the example above, and then click OK. If your port settings are configured correctly, you will return to the HyperTerminal window.
  • Page 46 PTQ-LNG ♦ Quantum / Unity Platform Setting Up the ProTalk Module Landis & Gyr Telegyr Interface Module Page 46 of 103 ProSoft Technology, Inc. May 29, 2007...

  • Page 47: Configuring The Module

    Configuring the Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Configuring the Module In This Chapter Before You Begin ..............47 Obtain the Sample Configuration Files........48 Edit the Sample Configuration File Sections ......49...

  • Page 48: Obtain The Sample Configuration Files

    PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module Browse to the configuration file on your PC and select it. Click Open. The configuration file appears in Notepad, ready for editing. Edit the Sample Configuration File Sections Note: It is important that you plan your configuration before modifying the configuration files.

  • Page 49: Edit The Sample Configuration File Sections

    Configuring the Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module When Notepad starts, open the File menu, and then choose Open. Navigate to the folder where you copied the configuration file on your PC and select the file.

  • Page 50: Backplane Configuration]

    PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module Module Type Parameter Module Type : PTQ-LNG The Module Type parameter is used to assign a name to the module that can be viewed using the configuration/debug port. Use this parameter to identify the module and the configuration file.
  • Page 51 Configuring the Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Write Register Start Write Register Start : 0 #Database start register where data placed from #processor The Write Register Start parameter assigns the starting address for data to retrieve from the processor.

  • Page 52: Lng Config]

    PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module The Error/Status Block Pointer parameter is used to specify which database register the error and status data will be stored in. Refer to the chapter on Status Data Definition for more information.

  • Page 53: Lng Port #]

    Configuring the Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module SBO Timer Duration is multiplied by the Timer Base 0 = 10 milliseconds 1 = 100 milliseconds 2 = 1 second 3 = 10 seconds...
  • Page 54 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module Stop Bits Stop Bits #1 or 2 stop bits for messages This parameter sets the number of stop bits to be used with each data value sent.

  • Page 55: I/O Chassis]

    Configuring the Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module 6.3.5 [I/O Chassis] This section defines chassis. [I/O Chassis] indicates how many chassis have been used from [Chassis Number 0] to [Chassis Number 6]. Chassis numbers 1 through 6 follow the same format as the [Chassis Number 0] section.

  • Page 56: Special Functions

    PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module 6.3.6 Special Functions Block 9992 – Select Before Operate If the module retrieves a BLOCK ID of 9992 from the PLC after it is issued the...
  • Page 57 Configuring the Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Word Offset in Example Data Description Block Address 300108 Pulse Lower Control point Lower at 100ms 100ms Control 300109 Pulse Lower Pulse Lower at 100ms...

  • Page 58: Uploading And Downloading The Configuration File

    You can connect directly from your computer's serial port to the serial port on the module to view configuration information, perform maintenance, and send (upload) or receive (download) configuration files. ProSoft Technology recommends the following minimum hardware to connect your computer to the module: 80486 based processor (Pentium preferred)
  • Page 59 Configuring the Module PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Required Software In order to send and receive data over the serial port (COM port) on your computer to the module, you must use a communication program (terminal emulator).
  • Page 60 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module Press [S] (Send Module Configuration). The message "Press Y key to confirm configuration send!" is displayed at the bottom of the screen. Press [Y]. The screen now indicates that the module is ready to send.
  • Page 61 Use the Browse button to choose a folder on your computer to save the file, and then click Receive. • Note: ProSoft Technology suggests that you upload the configuration file pre- loaded on your module. However, configuration files are also available on the ProSoft CD as well as the ProSoft Technology web site at http://www.prosoft-...
  • Page 62 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module The configuration file is now on your PC at the location you specified. You can now open and edit the file in a text editor such as Notepad. When you have finished editing the file, save it and close Notepad.
  • Page 63 Note: This procedure assumes that you are uploading a newly edited configuration file from your PC to the module. However, configuration files are also available on the ProSoft CD as well as the ProSoft Technology web site at http://www.prosoft-technology.com. ProSoft Technology, Inc.
  • Page 64 PTQ-LNG ♦ Quantum / Unity Platform Configuring the Module Landis & Gyr Telegyr Interface Module Select Ymodem as the protocol. Click the Send button. This action opens the Ymodem File Send dialog box. When the file transfer is complete, the module's configuration/debug screen indicates that the module has reloaded program values, and displays information about the module.

  • Page 65: Diagnostics And Troubleshooting

    LED status indicators on the front of the module provide information on the module's status. Reading Status Data From the Module The PTQ-LNG module provides the status data in each read block. This data can also be located in the module's database. 7.1.1...

  • Page 66: Required Hardware

    You can connect directly from your computer's serial port to the serial port on the module to view configuration information, perform maintenance, and send (upload) or receive (download) configuration files. ProSoft Technology recommends the following minimum hardware to connect your computer to the module: 80486 based processor (Pentium preferred)

  • Page 67: Using The Configuration/Debug Port

    Diagnostics and Troubleshooting PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module communication program. The following table lists communication programs that have been tested by ProSoft Technology. ProComm, as well as several other terminal emulation programs Windows 3.1...

  • Page 68: Main Menu

    Only use these commands if you are specifically directed to do so by ProSoft Technology Technical Support staff. Some of these command keys are not listed on the menu, but are active nevertheless.
  • Page 69 Diagnostics and Troubleshooting PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module disable the data analyzer. This action will allow the module to resume its normal operating mode. Viewing Block Transfer Statistics Press [B] from the Main Menu to view the Block Transfer Statistics screen.
  • Page 70 Only use these commands if you are specifically directed to do so by ProSoft Technology Technical Support staff. Some of these command keys are not listed on the menu, but are active nevertheless.

  • Page 71: Database View Menu

    Only use these commands if you are specifically directed to do so by ProSoft Technology Technical Support staff. Some of these command keys are not listed on the menu, but are active nevertheless.
  • Page 72 PTQ-LNG ♦ Quantum / Unity Platform Diagnostics and Troubleshooting Landis & Gyr Telegyr Interface Module And so on. The total number of register pages available to view depends on your module's configuration. Displaying the Current Page of Registers Again This screen displays the current page of 100 registers in the database.

  • Page 73: Backplane Menu

    Diagnostics and Troubleshooting PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Returning to the Main Menu Press [M] to return to the Main Menu. 7.1.7 Backplane Menu Press [B] from the Main Menu to view the Backplane Data Exchange List. Use this command to display the configuration and statistics of the backplane data transfer operations.

  • Page 74: Data Analyzer

    PTQ-LNG ♦ Quantum / Unity Platform Diagnostics and Troubleshooting Landis & Gyr Telegyr Interface Module Viewing Backplane Diagnostic Information Press [D] to view Backplane Diagnostic information. Use this command to display the configuration and statistics of the backplane data transfer operations between the module and the processor. The information on this screen can help determine if there are communication problems between the processor and the module.
  • Page 75 Diagnostics and Troubleshooting PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Important: When in analyzer mode, program execution will slow down. Only use this tool during a trouble-shooting session. Before disconnecting from the Config/Debug port, please be sure to press [M] to return to the main menu and disable the data analyzer.
  • Page 76 PTQ-LNG ♦ Quantum / Unity Platform Diagnostics and Troubleshooting Landis & Gyr Telegyr Interface Module Viewing Data in Hexadecimal Format Press [H] to display the data on the current page in hexadecimal format. Viewing Data in ASCII (Text) Format Press [A] to display the data on the current page in ASCII format. This is useful for regions of the database that contain ASCII data.

  • Page 77: Data Analyzer Tips

    Diagnostics and Troubleshooting PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module before returning to the main menu or disconnecting from the port. This action will allow the module to resume its normal operating mode. Returning to the Main Menu Press [M] to return to the Main Menu.
  • Page 78 PTQ-LNG ♦ Quantum / Unity Platform Diagnostics and Troubleshooting Landis & Gyr Telegyr Interface Module After you have selected the Port, Format, and Tick, we are now ready to start a capture of this data. The easiest way to do so is to go up to the top of you HyperTerminal window, and do a Transfer ->...

  • Page 79: Led Status Indicators

    Port not used in application ERR1 The PTQ-LNG is working normally. CFG Fail The PTQ-LNG module program has recognized an application error. This LED will also be turned on if any command presents an error. ERR2 Not used in application...

  • Page 80: Error Status Table

    The program maintains an error/status table that is transferred to the processor in each read block. You can use the error/status data to determine the "health" of the module. Refer to PTQ-LNG Status Data Definition (page 87) for data block structure.

  • Page 81: Reference

    8.1.1 Features and Benefits The PTQ-LNG module acts as a communication gateway between the Telegyr 8979 Rev. F version of the protocol and the Quantum backplane. The module functions as a Telegyr slave, receiving commands from the host. Data transfer...

  • Page 82: Hardware Specifications

    RS-232 handshaking configurable 500V Optical isolation from backplane 8.1.4 Functional Specifications The PTQ-LNG module supports the Landis & Gyr Telegyr 8979 Rev F slave protocol to the following specifications: Supports two serial ports emulating the protocol, each individually configurable for:...

  • Page 83: Ptq-Lng Functionality Overview

    Firmware Configuration PTQ-LNG Functionality Overview This section gives the reader a functional overview of the PTQ-LNG module. A thorough understanding of the information contained in this document is required for successful implementation of the module in a user application. If you already understand the content of this section, refer to the Module Configuration section to install and configure the module.

  • Page 84: General Concepts

    Backplane Data Transfer The PTQ-LNG module is unique in the way that the Quantum backplane is used. All data for the module is contained in the module's internal database. Data is...
  • Page 85 Reference PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module PTQ-LNG Database Map The following table shows the layout of the database. Start Address End Address Data Quantum Address Analog Inputs 401064 to 401363 Digital Inputs 401364 to 401413...

  • Page 86: Module Control Blocks

    These tasks are described in the following topics. Word 4000 contains the block ID that identifies the block to the PTQ-LNG module. The block structure is different for each block. Configuration Data Definition This section contains a listing of the parameters and addresses that are available in the PTQ-LNG database.

  • Page 87: Ptq-Lng Status Data Definition

    0, 1 Port 2 Use CTS (Y, N) 5039 0 to 255 Port 2 Slave ID PTQ-LNG Status Data Definition This section contains a listing of the data contained in the PTQ-LNG status data object. Register Content Description 6000 Program cycle counter This value is incremented each time a complete program cycle occurs in the module.

  • Page 88: Ptq-Lng Command Descriptions

    PTQ-LNG ♦ Quantum / Unity Platform Reference Landis & Gyr Telegyr Interface Module Register Content Description 6014 Number of responses - Port Contains the total number of messages sent out of the port. 6015 Number of errors sent - Port Contains the total number of message errors sent out the port.
  • Page 89 Reference PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Command Command Description ADC Reference Force Report - 5 This command returns hardcoded values to the host for one ADC point. The following values are returned for the -90%, 0% and 90% respectively, 205, 2048, and 3890.
  • Page 90 PTQ-LNG ♦ Quantum / Unity Platform Reference Landis & Gyr Telegyr Interface Module Command Command Description Accumulator Change Report - 12 This command is implemented in the module per the protocol specification. Up to 50 accumulators are supported by the module. This command returns the last frozen value for each accumulator if the freeze flag is set.

  • Page 91: Lng Message Format

    Reference PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Command Command Description Analog Group Defines - 35 This command is implemented per the protocol specification. Up to 300 analog values are supported by the module. Accumulator Preset - 36 This command is implemented in the module per the protocol specification.

  • Page 92: Master Data Block

    PTQ-LNG ♦ Quantum / Unity Platform Reference Landis & Gyr Telegyr Interface Module SHR: Short Response flag is set if the message does not contain any data blocks. RTU Address: The RTU address specifies the receiving RTU for the message.

  • Page 93: Rtu Message Header

    Reference PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module 8.6.4 RTU Message Header RTU ADDRESS The RTU Message Header consisted of two characters. The first character contains several RTU flags. The second character contains the address of the responding RTU.

  • Page 94: Rtu Crc

    PTQ-LNG ♦ Quantum / Unity Platform Reference Landis & Gyr Telegyr Interface Module L: The Last Block Mark is always set to one in the last Data Block of the messages, else it is reset to 0. Function Code: The function code is a 7 bit field that defines the purpose of the message.

  • Page 95: Does The Module Work In A Remote Rack

    Reference PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module 8.7.5 Does the module work in a remote rack? The module is designed to be located in the chassis with the PLC and will not operate in a remote chassis. If your application requires remote placement of the communication device you should investigate the other members of the ProLinx family such as the 4202-MNET-DFCM.
  • Page 96 PTQ-LNG ♦ Quantum / Unity Platform Reference Landis & Gyr Telegyr Interface Module Page 96 of 103 ProSoft Technology, Inc. May 29, 2007...

  • Page 97: Support, Service & Warranty

    When purchased from ProSoft Technology, Inc., the device has a 1 year parts and labor warranty (3 years for RadioLinx) according to the limits specified in the warranty.

  • Page 98: General Warranty Policy - Terms And Conditions

    Landis & Gyr Telegyr Interface Module General Warranty Policy – Terms and Conditions ProSoft Technology, Inc. (hereinafter referred to as ProSoft) warrants that the Product shall conform to and perform in accordance with published technical specifications and the accompanying written materials, and shall be free of defects in materials and workmanship, for the period of time herein indicated, such warranty period commencing upon receipt of the Product.

  • Page 99: Limitation Of Liability

    Reference PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Warranty Procedure: Upon return of the hardware product ProSoft will, at its option, repair or replace the product at no additional charge, freight prepaid, except as set forth below. Repair parts and replacement product will be furnished on an exchange basis and will be either reconditioned or new.
  • Page 100 PTQ-LNG ♦ Quantum / Unity Platform Reference Landis & Gyr Telegyr Interface Module Page 100 of 103 ProSoft Technology, Inc. May 29, 2007...

  • Page 101: Index

    Index PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Create a New Project • 9, 29 Index Data Analyzer • 74 Data Analyzer Tips • 77 Data Bits • 53 Database View Menu • 71 Diagnostics and Troubleshooting • 65 Digital Input Count •...
  • Page 102 Module • 62 PTQ-LNG Functionality Overview • 83 Transferring the Configuration File to Your PC • 59 PTQ-LNG Status Data Definition • 80, 87 Quantum / Unity Hardware • 6 Uploading and Downloading the Configuration File • 58 Use CTS Line • 54 Using the Configuration/Debug Port •...

  • Page 103: Prosoft Technology, Inc

    Index PTQ-LNG ♦ Quantum / Unity Platform Landis & Gyr Telegyr Interface Module Viewing Backplane Diagnostic Information • Viewing Block Transfer Statistics • 69 Viewing Configuration Information • 73 Viewing Data in ASCII (Text) Format • 72, 76 Viewing Data in Decimal Format • 72 Viewing Data in Floating Point Format •...
