MVI56E-MCMR ♦ ControlLogix Platform
Modbus Communication Module with Reduced Data Block
Adding Multiple Modules (Optional)
Important: If your application requires more than one MVI56E-MCMR module in the same project,
follow the steps below.
1 In the I/O C
shortcut menu, and then choose N
2 Select 1756-MODULE
3 Fill the module properties as follows:
Parameter
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly
Instance
Configuration Size
ProSoft Technology, Inc.
folder, click the right mouse button to open a
ONFIGURATION
Value
Enter a module identification string. The recommended value is
MCMR_2. You will need to link this name with the MSG paths for
the AOI.
Enter a description for the module. Example: Modbus
Communication Module with Reduced Data Block
Select D
ATA
Enter the slot number in the rack where the MVI56E-MCMR
module is located.
1
42
2
42
4
0
M .
EW ODULE
-INT (Very Important)
Start Here
User Manual
Page 31 of 223
