MVI56E-MCMR ♦ ControlLogix Platform
Modbus Communication Module with Reduced Data Block
2 Select the 1756-M
This action opens the N
3 Set the Module Properties values as follows:
Parameter
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance 4
Configuration Size
ProSoft Technology, Inc.
(G 1756 M
ODULE ENERIC
M dialog box.
EW ODULE
Value
Enter a module identification string. The recommended value is
MCMR, as this name will be linked automatically with the MSG
paths, irrespective of the slot location.
Enter a description for the module. Example: ProSoft
communication module for Modbus Serial protocol
communications.
Select D -INT (*Very Important*)
ATA
Enter the slot number in the rack where the MVI56E-MCMR
module is to be installed.
1
42
2
42
0
) from the list and click OK.
ODULE
Start Here
