Verify Communication

In This Chapter

Verify Master Communications ............................................................ 106

Verify Slave Communications .............................................................. 113
There are several ways to verify that the MVI56E-MCMR module is
communicating with the processor and with the Modbus network.

View the LED Status Indicators

View the Module Status in the RSLogix 5000 Controller Tags

View Diagnostics in ProSoft Configuration Builder
