LED Displays
LED Meaning
2 (green) Blue alarm
3 (yellow) Remote alarm
or out of sync
(yellow alarm)
4 (red) Loss of signal (red alarm)
11. Pull out the mains plug of the
OpenCom 120 / OpenCom 130
again and close the housing.
12. Reconnect the OpenCom 120 /
OpenCom 130 to the power
supply.

Configuration

The menu item S appears in the
2M
Configurator, menu PBX Configura-
tion: Ports after installation of the
S module. Configure the port in
2M
the input mask of this menu item.
Further information on this can be
found in the online help.
If the menu item S
2M
check whether or not the firmware
has to be updated. You need software
release 3.0 or higher. The current
firmware version is given in the menu
System Info: Versions.
is not displayed,
S Connector Module
2M
47
