– Supply voltage
– Supply power
– Range
a/b port
for analogue terminals
with pulse or DTMF dialling,
flash duration of 60 to 310 ms
– Supply voltage
– Supply power
– Feed current
– Range
V.24 port (COM)
for connection of a PC
– Range
Doorstation equipment module
for connection of doorstation
equipment
Contact load of actor 2
Contact load of actor 1
– Voltage range
Sensor
– Voltage range
130
40 V ± 10%
3 VA per U bus
pn
1,000 m
Basic module: . . . . . . . . . . . . . . . . . . . . . 4x
Add-on module: . . . . . . . . . . . . . . . . . . up to 24 x;
possible interface cards:
– 4 x a/b
– 8 x a/b
– 2 x S and 6 x a/b
0
40 V ± 10%
1.2 VA
25 mA
1,000 m
Basic module: . . . . . . . . . . . . . . . . . . . . . 1x (optional)
3 m
Basic module: . . . . . . . . . . . . . . . . . . . . . 1x (optional)
2 A / 125 V
10 A / 125 V
U = 5 V ... 30 V
≈
Switched by low AC voltage
U = 6 V ... 24 V
~
Technical Specifications
