centre LED lights up. The Ethernet
line between the hub of the corpo-
rate network and the LAN0 port is
properly connected if the right-hand
LED lights up.
To check whether there is a network
connection with your OpenCom 130,
enter the "ping IP address" com-
mand in "Run" in the Windows Start
menu (e.g. ping 192.168.99.254).
Question: How can I determine
the IP address of the
OpenCom 130?
To find out what the IP address is,
enter the code number
* 1 8 2
nected system telephones.
The code-number procedure
* 1 8 3
work mask.
Question: The network connec-
tion is functioning, but nothing is
displayed in the browser.
Enter the complete IP address of the
OpenCom 130 along with the proto-
col identifier, for example http://
192.168.99.254/.
Check whether the browser has
been configured for connection
through a proxy server. If so, deacti-
vate the "Connect through proxy
server" setting.
126
LAN
on one of the con-
also displays the net-
Question: You have just config-
ured the OpenCom 130 via the net-
work. Why is it not possible now to
establish a remote data transfer
network connection?
The network card and the communi-
cation (remote data transfer)
adapter cannot be run with the
same routing setting. Deactivate the
network card before connecting via
the dial-up network.
Question: Our network has grown
over time, with several segments
connected by one central router.
How can PCs from all segments be
connected with the OpenCom 130?
In the Configurator, use the LAN
setting in ISP to specify the central
router as the default gateway. If nec-
essary, deactivate any filter rules de-
fined for the ISP (NET Configura-
tion: Connections: ISP menu). If
several routers are configured for
your network in different segments,
you can enter extra static routes in
the NET Configuration: Easy Access:
Routes menu.
In our network the OpenCom 130
dynamically issues the IP addresses
by DHCP. Can I firmly assign the IP
address for our internal server PCs
(mail, Web)?
You need a static address assign-
ment for these PCs. Make the appro-
priate assignment entries in the
Configurator (NET Configuration:
Frequently Asked Questions
