2M
The S
2M
you to operate an OpenCom 120 /
OpenCom 130 on a primary multi-
plex port. This port provides up to 30
voice channels. You can also use the
S port to network two systems,
2M
e.g. in order to use the
OpenCom 120 / OpenCom 130 as a
subsidiary system or DECT server.
PCM LAN 1
Location of the S
S
2M
Location of the S
44
S Connector Module
2M
Connector Module
connector module allows
LAN 2
Sync Sensor Default setting
S 1 S 2 S 3
0 0 0
ext ext ext
R R R
S S 1 S 2 S 3
2M 0 0 0
int int int
port on the connector module of the OpenCom 120
2M
U
pn
U 1 S 2
2+3
pn
0
a/b
3+4
RJ45 RJ45 a/b LAN
S 1 S 2 1+2
0 0
port on the basic module of the OpenCom 130
2M
Note: The maximum cable attenu-
ation between the OpenCom 120 /
OpenCom 130 and the other system
(NT or telephone exchange) must not
exceed 6 dB. This corresponds to a
length of approx. 150 to 200 m, de-
pending on the type of cable used.
