LAN-to-LAN Settings

Have you made the network
settings for the OpenCom?
Configure the LAN-LAN
connection. "NET Configuration:
Connections: LAN-LAN"
Yes
Yes
Flowchart: Configuring the LAN-to-LAN Settings
Configuration Guide
LAN No
Yes
Protocol
Telephone number local
IP address local
Network mask local
CLID
No
User name local
Password local
Telephone number remote
IP address remote
Network mask remote
CLID
No
User name remote
Password remote
Direction of connection
Maximum connection
time per month
Maximum idle time
Add internal telephone
number to the incoming call
distribution scheme.
Finished
NET Configuration: Configure the network
Easy Access settings for the OpenCom.
Select between PPP and HDLC transparent.
Enter the internal telephone number.
Enter the local IP address.
Enter the local network mask.
Authorisation method of the local
LAN: CLID, PAP or CHAP?
Specify the user name with which the
remote LAN can access a destination.
Specify the password with which the
remote LAN can access a destination.
Specify the telephone number of the remote LAN access.
Specify the IP address of the remote LAN.
Specify the network mask of the remote LAN.
Authorisation method of the remote
LAN: CLID, PAP or CHAP?
Specify the user name with which
the remote LAN can be accessed.
Specify the password with which
the remote LAN can be accessed.
Select the direction of the connection.
Specify the maximum number of minutes per month
the connection to the remote LAN can be set up for.
Set the maximum idle time after which a
connection to the remote LAN is cleared down.
LAN-to-LAN Settings
119
