S
2M
The S
2M
you to operate an OpenCom 120 on
a primary rate access. This access
provides up to 30 voice channels.
You can also use the S
work two systems, e.g. in order to
use the OpenCom 120 as a subsidi-
ary system or DECT server.
PCM LAN 1
Location of the S

Installation

Please note: The module should
only be installed by trained person-
nel.
DANGER! The device con-
tains hazardous voltages.
1. Pull out the mains plug of the
OpenCom 120.
40
S Connector Module
2M
Connector Module
connector module allows
port to net-
2M
LAN 2
Sync Sensor Default setting
S 1 S 2 S 3
0 0 0
ext ext ext
R R
R
S S 1 S 2 S 3
2M 0 0 0
int int int
port on the connector module of the OpenCom 120
2M
Note: The maximum cable attenu-
ation between the OpenCom 120 and
the other system (NT or telephone ex-
change) must not exceed 6 dB. This
corresponds to a length of approx.
150 to 200 m, depending on the type
of cable used.
Intercom/Door opener Intercom/
S 4 S 5 S 6
0 0 0
ext ext ext
R R R
COM
S 4 S 5 S 6
0 0 0
int int int
2. Open the housing of the
OpenCom 120.
3. For some models of the
OpenCom 120 a separate mod-
ule cover exists. Remove the
cover of the module. To do this,
push back the two locking le-
vers, (1) and (2), and lift off the
cover.
U U
U
pn pn
Relay
pn
11/12 13/14
9/10
E
Actuator U U U U
pn pn pn
1 + 2 1/2 3/4 5/6 7/8
U
U
pn
pn
15/16
17/18
a/b a/b
pn
1/2 3/4
