RUNTIME: The Power 775 is powered on, and the operating system is not necessarily
booted.
PENDINGPOWEROFF: The Power 775 has received a power-off command.
LOW_POWER_IPL: Not implemented yet. Used during installation.
RUNTIME_CNM_EXCLUDED: CNM is not used and the drawer mis-configured.
STANDBY_CNM_EXCLUDED: CNM is not used and the drawer mis-configured.
RUNTIME_CNM_UNREACHABLE: CNM has lost contact with the drawer.
STANDBY_CNM_UNREACHABLE: CNM has lost contact with the drawer.
FSP status: The following FSP status indicates that a drawer mis-configuration exists
(EXCLUDED) or that CNM lost contact with the drawer (UNREACHABLE):
RUNTIME_CNM_EXCLUDED or STANDBY_CNM_EXCLUDED
RUNTIME_CNM_UNREACHABLE or STANDBY_CNM_UNREACHABLE
An example of an FSP with EXCLUDED status is when the LNMC topology does not match
the topology that is defined in the cluster DB and CNM, as described in 4.2.7, "Correcting
inconsistent topologies" on page 257.
An FSP status of UNREACHABLE indicates a physical hardware problem on the drawer or
FSP or possibly an LNMC configuration issue with the FSP.

4.2.5 Verifying CNM to FSP connections

The lsnwcomponents command displays the BPAs and FSPs that are reachable via the
service network, as shown in Example 4-19.
Example 4-19 Displaying the BPAs and FSPs
# lsnwcomponents
BPA Primary ip=40.6.0.1 MTMS=78AC-100*992003H FR006
BPA Backup ip=40.6.0.2 MTMS=78AC-100*992003H FR006
FSP Primary ip=40.6.4.2 MTMS=9125-F2C*02C6946 FR006-CG06-SN051-DR3
FSP Backup ip=40.6.9.1 MTMS=9125-F2C*02C6A26
FSP Primary ip=40.6.12.2 MTMS=9125-F2C*02C6A86 FR006-CG14-SN005-DR3
FSP Primary ip=40.6.6.2 MTMS=9125-F2C*02C69B6 FR006-CG08-SN004-DR1
FSP Backup ip=40.6.8.1 MTMS=9125-F2C*02C6A06
FSP Primary ip=40.6.5.2 MTMS=9125-F2C*02C6986 FR006-CG07-SN004-DR0
FSP Primary ip=40.6.7.2 MTMS=9125-F2C*02C69D6 FR006-CG09-SN004-DR2
FSP Primary ip=40.6.2.2 MTMS=9125-F2C*02C68D6 FR006-CG04-SN051-DR1
FSP Primary ip=40.6.1.2 MTMS=9125-F2C*02C68B6 FR006-CG03-SN051-DR0
FSP Backup ip=40.6.11.1 MTMS=9125-F2C*02C6A66
FSP Backup ip=40.6.3.1 MTMS=9125-F2C*02C6906
FSP Backup ip=40.6.10.1 MTMS=9125-F2C*02C6A46
FSP Backup ip=40.6.2.1 MTMS=9125-F2C*02C68D6
FSP Backup ip=40.6.1.1 MTMS=9125-F2C*02C68B6
FSP Primary ip=40.6.11.2 MTMS=9125-F2C*02C6A66 FR006-CG13-SN005-DR2
FSP Primary ip=40.6.3.2 MTMS=9125-F2C*02C6906 FR006-CG05-SN051-DR2
FSP Backup ip=40.6.4.1 MTMS=9125-F2C*02C6946
FSP Primary ip=40.6.9.2 MTMS=9125-F2C*02C6A26 FR006-CG11-SN005-DR0
FSP Backup ip=40.6.12.1 MTMS=9125-F2C*02C6A86
FSP Backup ip=40.6.6.1 MTMS=9125-F2C*02C69B6
FSP Primary ip=40.6.8.2 MTMS=9125-F2C*02C6A06 FR006-CG10-SN004-DR3
