Example 3-44 lsnwgc command output
# lsnwgc -a
Master: FR006-CG06-SN051-DR3-HB1 Counter Id: 0xd0
No. of Configured Backups: 11
FR006-CG12-SN005-DR1-HB1
FR006-CG04-SN051-DR1-HB1
FR006-CG13-SN005-DR2-HB1
FR006-CG05-SN051-DR2-HB1
FR006-CG10-SN004-DR3-HB1
FR006-CG08-SN004-DR1-HB1
FR006-CG07-SN004-DR0-HB1
FR006-CG09-SN004-DR2-HB1
FR006-CG11-SN005-DR0-HB1
FR006-CG14-SN005-DR3-HB1
FR006-CG03-SN051-DR0-HB1
Broadcast Frequency (in 2Ghz counter cycles) - 0xffffff
Takeover Trigger (Number of Broadcasts) - 0x10
Invalid Trigger (Number of Broadcasts) - 0xff
Range Constant (Added when a backup is stale) - 0x1000
lsnwlinkinfo
For this command, we list the help description that is shown in Figure 3-18. A typical output is
shown in Example 3-45.
# lsnwlinkinfo -h
Usage: lsnwlinkinfo [ { -f <frame> | --frame <frame> } [ { -c <cage> | --cage
<cage> } [ { -m <hubmodule> | --hub_module <hubmodule> } ] ] | { -s <supernode>
| --supernode <supernode> } [ { -d <drawer> | --drawer <drawer> } [ { -m
<hubmodule> | --hub_module <hubmodule> } ] ] ] [ -p | --page ] [ -h | --help ]
The options can be given either with '-' or '--'.
Figure 3-18 lsnwlinkinfo command flag description
The lsnwlinkinfo command lists the integrated switch network links information. The input
and output values are the same as the values from the lsnwexpnbrs command. The
lsnwlinkinfo command also displays the status of the link, as shown in Example 3-45. The
value of the status attribute is: [ UP_OPERATIONAL ]
Example 3-45 lsnwlinkinfo command output
# lsnwlinkinfo
FR006-CG04-SN051-DR1-HB0-LL0 UP_OPERATIONAL ExpNbr: FR006-CG04-SN051-DR1-HB3-LL0
ActualNbr: FR006-CG04-SN051-DR1-HB3-LL0
FR006-CG04-SN051-DR1-HB0-LL1 UP_OPERATIONAL ExpNbr: FR006-CG04-SN051-DR1-HB5-LL0
ActualNbr: FR006-CG04-SN051-DR1-HB5-LL0
FR006-CG04-SN051-DR1-HB0-LL2 UP_OPERATIONAL ExpNbr: FR006-CG04-SN051-DR1-HB1-LL2
ActualNbr: FR006-CG04-SN051-DR1-HB1-LL2
[...]
