Job Command File for Hybrid (MPI + OpenMP) job
Figure 2-22 shows a sample job command file for a Hybrid (MPI + OpenMP) job. This job is
requesting two nodes, eight tasks per node and four threads per task. The total requested
cores are 64.
#!/bin/ksh
# @ job_name = myjob.hybrid
# @ job_type = parallel
# @ class = X_Class
# @ output = $(job_name).out
# @ error = $(job_name).err
# @ env_copy = all
# @ bulkxfer = yes
# @ network.MPI = sn_all,shared,US
# @ rset = RSET_MCM_AFFINITY
# @ mcm_affinity_options = mcm_mem_req mcm_distribute mcm_sni_none
# @ task_affinity = core(4)
# @ cpus_per_core = 1
# @ parallel_threads = 4
# @ node = 2
# @ tasks_per_node = 8
# @ collective_groups = 64
# @ queue
export MP_LABELIO=yes
export LANG=en_US
export MP_SHARED_MEMORY=yes
export MP_SINGLE_THREAD=yes
export MP_DEVTYPE=hfi
export MP_USE_BULK_XFER=yes
export MP_RDMA_ROUTE_MODE="hw_indirect"
export MP_FIFO_ROUTE_MODE="hw_indirect"
poe ./hybrid.exe
Figure 2-22 Job Command File for Hybrid (MPI + OpenMP) job
If the job command file is composed correctly and as you intended, you submit the job by
using the llsubmit command. Example 2-15 shows the usage of the llsubmit command and
the message that is received after the command is issued.
Example 2-15 llsubmit command
$ llsubmit ll_mpi.cmd
llsubmit: The job "c250f10c12ap02-hf0.ppd.pok.ibm.com.49" has been submitted.

2.6.2 Querying and managing jobs

Querying and managing jobs is described in this section.
Querying job status
After a job is submitted by using the llsubmit command, you use the llq command to query
and display the LoadLeveler job queue. Example 2-16 on page 147 shows the usage of the
llq command and the message that is received after the command is issued.
