OPERATION

GENERAL ELECTROTHERAPY WAVEFORM SET UP

The following information is an example of step by step set up for the Electrotherapy waveforms. All waveforms in the Intelect Advanced
Therapy System are set up and edited in the same basic fashion. The following set up instructions use IFC Traditional (4p) Waveform.

Prepare Patient

Refer to pages 35 through 38 for electrode
selection, preparing patient, and securing
electrodes.

Select Modality

Press the Electrotherapy button on the
Home screen.
ELECTROTHERAPY
BUTTON

Select Waveform

Press button beside the desired waveform
from the listing on the screen.
PRESS DESIRED WAVEFORM BUTTON
Refer to Specifications section of this
manual for all available waveforms on the
Intelect Advanced Therapy System.
43
Intelect® Advanced Therapy System

View Waveform Description

Press the Waveform Description button
to view text explaining the waveform
rationale.
WAVEFORM DESCRIPTION
BUTTON
Press the Next Page button to view
additional text. Press the Back button to
return to the Treatment Review screen.
Supplied by EME Services Ltd
NEXT
PAGE
BUTTON
BACK
BUTTON
