NOMENCLATURE

USER INTERFACE

15
16
14
13
12
11
10
9
8
6
1
2
3
4
5
6
7
12
Intelect® Advanced Therapy System
1. Rear Access Panel (See Page 11)
2. User Interface (Color Shown)
3. Ultrasound LED Coupling Indicator
(Combination only)
4. Ultrasound Applicator- 5 cm
(Optional 1 cm 2 , 2 cm 2 and 10 cm
applicators available (Combination only)
5. Intensity Knob
6. Cable and Lead Wire Hook
7. Front Access Panel (See Page 11)
8. Start Button
9. Pause Button
10. Stop Button
11. Clinical Resources Library Button
12. Home Screen button
13. Back Button
14. Patient Data Card and sEMG Data Card Port
15. User Set Up and Parameter Control buttons
16. Multimedia Card (MMC) Port
