NOMENCLATURE

SYMBOL DEFINITIONS

Below are the definitions for all of the symbols used in the Intelect Advanced hardware and software. Study and learn these symbols before
any operation of the system.

System Hardware Symbols

CONTRAST CONTROL
NOT FUNCTIONAL ON
COLOR SYSTEMS
ON/OFF SWITCH
DATA PORT
MULTIMEDIA CARD,
PATIENT DATA CARD,
AND EMG DATA CARD
S
STOP TREATMENT
PAUSE TREATMENT
START TREATMENT
PATIENT INTERRUPT
SWITCH
THERAPY
INTENSITY
CONTROL CHANNEL 1
LEAD WIRES
HOME CHANNEL 2
LEAD WIRES
CLINICAL
RESOURCES
LIBRARY
MICROCURRENT PROBE
BACK
CHANNEL 1/2
OPERATOR
ULTRASOUND
REMOTE
APPLICATOR
CONTROL
OPTIONAL
System
Optional Module and Accessory Symbols
Software Symbols

Operator Remote

MOVE UP
MOVE DOWN
MOVE RIGHT
MOVE LEFT
M
ACCEPT AND
RETURN
DO NOT ACCEPT

Battery Module

AND RETURN
PAD CONTACT QUALITY
SINGLE CHANNEL GRAPH
PAD CONTACT QUALITY
DUAL CHANNEL GRAPH
13
Intelect® Advanced Therapy System
Channel 3/4
Electrothrapy
INCREASE
Module
INTENSITY
PATIENT INTERRUPT SWITCH
DECREASE
INTENSITY
PAUSE
CHANNEL 3 LEAD WIRES
TREATMENT
MANUAL
STIMULATION
CHANNEL 4 LEAD WIRES
MICROCURRENT PROBE
CHARGE LEVEL
CHANNEL 3/4 OPERATOR
REMOTE CONTROL
BATTERY CHARGING OPTIONAL
