INSTALLATION/REMOVAL
INSTALLATION CHANNEL 3/4 ELECTROTHERAPY MODULE (continued)

Disconnect Mains Power

DISCONNECT THE SYSTEM FROM THE
POWER SOURCE (OUTLET OR REMOVE
BATTERY MODULE IF INSTALLED) BEFORE
ATTEMPTING ANY MAINTENANCE,
INSTALLATION, REMOVAL, OR REPLACEMENT
PROCEDURES TO PREVENT ELECTRICAL
SHOCK AND POSSIBLE DAMAGE TO SYSTEM.
Disconnect the Mains Power Cord from
the power supply. Remove the Rear Access
Panel and disconnect the Mains Power
Cord from the Therapy System.
MAINS
POWER
CORD

Remove Lead Wires and Accessories

Remove the Front Access Cover and
disconnect the Lead Wires and Accessories
from the Therapy System.
REMOVE LEAD
WIRES AND
ACCESSORIES
REAR
ACCESS
PANEL

Remove Therapy System from Cart

Remove the Therapy System from the
Therapy System Cart, if equipped. Refer to
the Therapy System Cart User Manual for
proper instructions.
Place Therapy System face down on a clean
working surface protected with a soft, clean
fabric to prevent damage to the lens.
NOTE:
Do not remove the sEMG Module, if
installed. The sEMG Module will not
interfere with installation of the Channel
3/4 Electrotherapy Module.
98
Intelect® Advanced Therapy System
EMG
S
MODULE
LANYARD
